Rockford Fosgate Stage 1 Audio System for 2024+ Polaris RZR XP 1000 (100W)

Description

 Rockford Fosgate ’24+ Polaris RZR XP 1000 Stage 1 Aftermarket 100-Watt Audio System

The all-new Rockford Fosgate aftermarket Stage 1 is a premium 100-Watt 2-speaker audio system for 2024+ Polaris RZR XP and features our PMX-1 Bluetooth® source unit as your audio controller. The PMX-1 is an IPX6 rated and features a built-in amplifier that powers Element Ready front 6.5” coax speakers. All enclosures are custom fabricated and designed to fit seamlessly into the interior without loss of functional cabin space. The system features a complete wiring harness with OEM style connectors for true plug-and-play integration and allows for future expansion of two additional rear speakers.

Dynamic Performance: Featuring a plug-and-play design, this system is equipped with two 6.5-inch speakers and a 2.3-inch source unit, delivering the perfect balance of powerful performance and effortless installation.

Plug-and-Play Design: Minimal drilling, no cutting and designed to work right out of the box. Simple installation ensures less time in the garage and more time out riding.

Bluetooth Control: With Bluetooth connectivity it’s easy to control your music and take your playlist with you no matter where you go.

Element Ready: Purpose Built for the outdoor environment, Rockford’s Element Ready products are built to stand up to Water, Salt, and UV, making sure your products stand the test of time.

Compatibility: Refer to our compatibility chart to verify fitment before purchasing.

Features:

• Dust Resistant: Displays and motor structures are sealed tight so they look and sound as clear as possible no matter how many times you hit the trails.
• IPX6 Water Intrusion Rating: Water projected in powerful jets from any direction shall have no harmful effects.
• MP3 Playback: This source unit supports MP3 file format playback.
• USB Playback: This source unit supports playback from a USB device.
• Stainless Hardware: Stainless hardware is used to its natural resistance to corrosion and rusting. This ensures electrical connections will not degrade over time due to exposure to the elements.
• Corrosion Protection: Components are tested for salt spray corrosion resistance.
• Thermal Shock Resistant: Components are designed to withstand extreme temperature fluctuations ensuring they perform day-in and day-out.
• UV Inhibitor Materials: Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in accordance with ASTM D4329 testing and certification procedures.
• Vibration Resistant: Components are able to withstand shock and vibration conditions common with outdoor vehicles.
• Water Resistant: IPX Ratings allow for the components to be directly sprayed with water without ingress.

Specifications:

Speaker Qty	2
Mounting Hardware	Yes
Amplifier Type	Internal
Grille-Trim Ring Included	Yes
Expansion Ports	None
Total Power	100 Watts
Shipping Weight	25 Lbs. (11.3 Kg)
Included In The Box	(1) PMX Wiring Harness PMX-DK (4) Torx plastic tapping screw, ¼” x 1” long (1) PMX radio bracket RZR24XP-FSE (1) Driver FSE (1) Passenger FSE (6) Torx Bolt M6 x 0.75mm, 14mm long (12) Hex Bolt M4 x 0.7mm, 22mm long (2) Hex Screw M6 self-tapping (2) Tube clamp mount bracket
Dynamic Performance	Features at a Glance
The RZR24XP-STG1 is a performance, 2-speaker, 100-watt front audio system Components: (1) Bluetooth Source Unit (2) 6.5” M0 Element Ready Speakers Installation: (3) Hours Typical Upgrade This Kit: (1) PMX-ANT Powered Antenna (1) PMX-USBP USB Extension Port (1) PMX-BTUR Steering Wheel Remote (2) M0WL-65MB 6.5″ M0 Rear Moto-Cans (1) PMX-3 SiriusXM Ready Source Unit (1) MX-CAM-RZR14 Backup Cam (for PMX-3)	Includes wired antenna Element Ready to withstand the harsh outdoor environment like dust, water, and UV rays True plug-and-play design with OEM connectors for easy installation Direct bolt into vehicle using OEM mounting holes. Minimal drilling required PMX-1: Punch Marine Grade Media Receiver with 2.3″ Dot Matrix Display RZR24XP-DK: source unit dash kit for select 2024+ RZR models RZR24XP-FSE: 6.5″ front speaker enclosures for select 2024+ RZR models Enclosures for speakers/subwoofer integrate with no loss of passenger space Video installation tutorial with easy-to-follow instructions M0-65B: M0 6.5″ Element Ready Speakers – Black

Fitment:

2-Seat Models	2024	2025
RZR XP 1000 Sport	✓	✓
RZR XP 1000 Premium RF1	✓	✓
RZR XP 1000 Ultimate RC, RF3	✓	✓
4-Seat Models	2024	2025
RZR XP 1000 Sport	✓	✓
RZR XP 1000 Premium RF1	✓	✓
RZR XP 1000 Ultimate RC, RF3	✓	✓
[ ] Brackets indicate nomenclature used on earlier models and inherited on later models.
* Optional package available from factory.
RC Ride Command comes factory equipped. Required for Rockford Fosgate audio kits with “RC” in model number.
RF1 Stage 1 Factory equipped with Rockford Fosgate premium audio (2 front speakers). Needs to be bypassed.
RF2 Stage 2 Factory equipped with Rockford Fosgate premium audio (2 tweeters, 2 front speakers, 400W amp). Needs to be bypassed.
RF3 Stage 3 Factory equipped with Rockford Fosgate premium audio (2 tweeters, 2 front speakers, 2 rear speakers, 400W amp). Needs to be bypassed.

Installation Instructions:
